SPECIFICATIONS

• Color : Black
• Dimension :
  Structure 370(L)* 201(W)* 435(H)mm
  Case: 405(L)x201(W)x435(H)mm
  Carton: 488(L)x258(W)x461(H)mm
• Material : Structure Back Plate made of SPCC in 0.6mm, Internal Structure made of SPCC in 0.50mm;
  Panel: ABS Plastic + Anti-Dust Cover; Iron Net included the Front Glass
• M/B Type : ATX, Micro-ATX, Mini-ITX
• External : None
• Internal : 3.5″x2 + 2.5″x2 + 2.5″x2 (Not allow fans in inner-front)
• Converted Bracket : With 2×2.5″ SSD Bracket
• CPU MAX H : Can fix up to 160mm CPU
• VGA MAX L : Can fix up to 350mm VGA
• I/O Panel : USB3.0x1 + USB2.0x2; Normal Microphone x1 & HD Audio x1;
• Cord Design : Back plate wire routing (20mm + front 40mm space)
• Expansion PCI Slots : Standard x7
• Cooling System :
  Font: 12cm Fan x3 Standard 240mm water cooling (optional)
  Rear: 12cm Fan x1
  Top: 12cm Fan x2 or 14cm x2 or 240mm water cooling – RAM height no more than 32mm (optional)
• Structure Hang : Black Plate with 2 Hangs to organize CPU cooler cable, top cover fan’s cable & rear fan’s cable efficiently;
• PSU : ATX-Upto 180mm length/PS2 (Optional)
